• Used for cutting wood only
• Vertical blade angle adjustable: 52 degrees left, 60 degrees right
• Built-in adjustable fences and clamps
• Crosscut up to 3 1/2″ by 13 1/2″ lumber

• Used for making either straight or curved cuts in wood and some plastics
• Table can be adjusted to a specific

• Multiple sanding surfaces for greater flexibility
• Not for use with aluminum
• Used to smooth corners, edges and for other light duty grinding

• Used for making holes in both wood and metal
• Digital spindle speed control
• Multiple clamping options for flexibility
• Many different styles of bits to choose from

• • Can plane wood up to 12″ wide and a minimum of 12″ long
  • Removes a small amount of material from the surface of wood to produce a very smooth surface
  • Removes 1/16” maximum per pass

• Feeds wood through machine to control removal rate

• Used to create intricate cuts in wood and some plastics
• Adjustable head speed for different materials
• Table adjusts to specific angle from the horizontal

• Used to remove a relatively large amount of wood from internal curved surfaces
• Different size spindles available to match the curve being sanded
• Spindle moves up and down as well as spinning to ensure material is removed without burning
• Table can be tiled to accommodate for different angled features

• Used for hollowing and carving wood and some plastics
• Collet capacity: 1/2”
• Main body stroke: 2 7/16”
• Many different router bits to choose from

SAWSTOP 10″ INDUSTRIAL CABINET SAW (ICS31230)

• Used for making many types of cuts in wood and some plastics
• Has specialized safety systems to reduce (not eliminate) the risk of serious injury
• Dado blades available for cutting channels in wood

• Used to create a curve in sheet    metal or wire with a minimum final diameter of 4 1/2”
• Not to exceed 50” wide 16 gauge mild steel
• 3” diameter rollers
• Adjustable for material thickness
• Can also roll wire in thicknesses of 0.513”, 0.407”, and 0.335”

Used for manually machining components in 2D

• Can be used manually to create simple rectangular geometries
• Can be used semi-automatically with conversational control to do more complicated features (lines, rectangular pockets, odd diameter circular pockets, hole patterns, etc.)
• Variety of supporting tools and equipment

Used for manually machining components in 2D and 3D

• Can be used manually to create simple rectangular geometries
• Can be used semi-automatically with conversational control to do more complicated features (lines, rectangular pockets, odd diameter circular pockets, hole patterns, etc.)
• Can use .nc files to run in full 3-axis mode with a single tool
• Variety of supporting tools and equipment

• Used for machining round symmetrical components
• Variable speed up to 1200 rpm
• Can machine stock from 3/64” to 12” diameter
• 40″ between Centers
• Two axis digital readout
• Two axis auto-feed

• Used for rough-sizing metals and some plastics
• Multiple clamping options for flexibility
• Hydraulically powered table feed

• Used for cleaning and de-burring metal components
• Wire wheel used for removing rust, gasket material, etc.
• 2 different roughness stone wheels used for removing material from ferrous metals only
• Polishing wheel for making smooth surfaces or de-burring softer metals

• Used for smoothing edges and de-burring metal components
• Produces smoother finish than bench grinder

• Used for making holes in both wood and metal
• Digital spindle speed control
• Multiple clamping options for flexibility
• Many different styles of bits to choose from

• Used for rough sizing metal stock, especially long pieces
• Blade tilts for making miter cuts
• Adjustable feed rate and blade speed
• Multiple clamping options for flexibility

• Used to make clean accurate cuts in metal up to 3/4”
• Can cut up to 22” per minute when cutting mild steel
• Can be paired with PlasmaCAM CNC table

Used to make accurate bends in square and round tubing

• Bends round tubing that is 1/2” to 2 1/2” diameter
• Bends square tubing that is up to 1 1/2” diameter
• Bends schedule 40 pipe up to 2” in diameter
• Uses 10 ton pneumatic cylinder

• Used to weld both steel and aluminum
• Welds steel that is 0.004” to 0.25” thick
• Welds aluminum that is 0.02” to 0.25” thick

Used to weld mild steel. Can be used to weld aluminum or stainless steel with the special setups.

• Welds steel that is 22 gauge up to 1/2” thick
• The Miller Spoolmatic Spool Gun can be attached for welding aluminum up to 1/4” thick

• Welds Aluminum that is 18 gauge up to 1/2” thick

Used for spot welding thin materials together

• 1/8″combined thickness capacity
• Used to spot weld uncoated mild steel, galvanized steel, or stainless sheet steel
• Throat depth 6″

Used for cutting, welding and brazing metals

• Produces rough edged cuts that must be finished by grinding or sanding
• Different tips available for different operations
• Can be used to heat parts

Used for punching, shearing, notching, and bending mild steel

• Capacity up to 56 Tons
• Can shear pieces up to 10″ wide and up to 3/4″ thick (exact capacity dependent on size and tonnage requirements)
• Can punch holes in materials less than an inch (size depends on diameter and tonnage)
• Can notch materials up to 3/8″ thick
• Workpiece may be deformed slightly from the operation
• Has chart displaying maximum working limits for different materials
• Many different dies to choose from

Hydraulic press for removing or installing press-fit components and bending components

• 75 Ton Capacity
• 31″ Working Width
• 9.8″ Stroke
• 24″ Wide bending attachment for bending sheet metal available

Used for bending sheet metal and some plastics

• 50″ max bending width
• Maximum working thickness is 12 gauge mild steel

TENNSMITH SHEAR

Used for cutting sheet metal and some plastics

• Cut width up to 50″ wide
• Cuts up to 16 gauge mild steel
• Cuts up to 20 gauge stainless steel
• Cuts up to .09″ aluminum

Used to make notches in sheet metal

• Notches will be “V” shaped with 90° corner
• Sheet metal may exhibit some distortion after notching process

Used for quickly machining complex components out of metal stock

• Machines 2D or 3D components
• 10,000 RPM Spindle
• Indexer may be installed to allow rotation of workpiece about a fourth axis in small increments
• Bed travels 30” (X-axis) by 20” (Y-axis) by 20” (Z-axis)
• Uses MasterCAM .NC code to program component geometry
